Gridbots BAT: Next-Generation Gunshot Detection System with Precision Tracking and Real-Time Response

Indian robotics and AI company Gridbots has recently unveiled the Gridbots BAT—a state-of-the-art gunshot direction-finding system that is revolutionizing how security forces, military units, and law enforcement agencies respond to gunfire threats. Combining precision, real-time responsiveness, and advanced detection capabilities, the BAT system brings a robust and highly accurate solution to identifying and pinpointing gunshot locations.

At the heart of Gridbots BAT is its exceptional detection accuracy. The system provides directional precision with an accuracy of ±5 degrees in both elevation and azimuth, alongside distance accuracy within ±4% FS (Full Scale). This capability allows operators to quickly and accurately determine the origin of gunfire, which can be critical in high-stakes environments such as urban combat zones, crowd control situations, and counter-terror operations.

Advanced Differentiation and Real-Time Tracking

What sets BAT apart is its sophisticated differentiation capability. Unlike basic gunshot detectors, BAT can differentiate between multiple types of gunfire by selectively focusing on specific frequencies. This means the system isn’t easily misled by irrelevant background noises in noisy environments. BAT’s ability to focus on particular sounds makes it ideal for operations in settings with ambient noise—whether in urban environments, open fields, or mountainous terrains.

BAT also allows for continuous monitoring and tracking of multiple gunfire sources. It utilizes a tracking mode that provides situational awareness by monitoring gunfire activity across 360 degrees, ensuring comprehensive protection during active engagements. This 360-degree coverage, coupled with a long detection range of up to 1,500 meters, enables wide-area monitoring across large perimeters, making it suitable for remote surveillance, border security, and high-value asset protection.

Integrated RTK GPS and Remote-Controlled Weapon Station (RCWS) Connection

A standout feature of the BAT system is its integration with Real-Time Kinematic (RTK) GPS technology, which provides highly precise geographic positioning for detected gunfire sources. This GPS integration supports precise location mapping of gunfire within moments, allowing operators to quickly visualize the threat location. Moreover, BAT can interface directly with a Remote-Controlled Weapon Station (RCWS). This connection enables immediate response by auto-targeting the source of the gunfire, enabling rapid and accurate threat neutralization without the need for manual intervention.

Sophisticated Signal Processing and Power Efficiency

The BAT system’s gunshot detection and analysis are powered by advanced digital signal processing (DSP) technology. It leverages seven sensor-DSP units that work together to accurately detect gunfire and isolate specific frequencies. This multi-sensor approach is further enhanced by high-selectivity bandpass filtering, which helps reduce false positives by filtering out irrelevant sounds. BAT’s wide frequency response range—from 500 Hz to 20,000 Hz—enables it to capture a variety of gunshot sounds, covering everything from small firearms to larger-caliber weapons.

Energy efficiency is another strength of BAT, as it consumes less than 50 watts, making it a practical choice for mobile and remote applications. It can be mounted on various platforms, including unmanned ground vehicles (UGVs), tactical vehicles, and static installations. Once activated, BAT is operational within seconds, requiring less than five minutes for full deployment, which is essential for rapid-response situations.

Technical Excellence and Deployment Versatility

Designed to perform in a range of environmental conditions, BAT operates effectively in both high-temperature and extreme cold settings. This ruggedization makes it adaptable for challenging terrain, including mountainous regions, dense urban settings, or open landscapes where detecting long-range threats is crucial. Additionally, with a refresh rate of 1,000 Hz, the system processes incoming data with near-instantaneous speed, ensuring operators have continuous real-time information for quick decision-making.

A New Standard for Gunshot Detection Systems

Gridbots BAT represents a leap in gunshot detection technology by delivering a blend of precision, speed, and versatility in one system. As it allows for multi-source tracking and automatic targeting, BAT gives security and defense forces a critical advantage in managing and neutralizing threats. Its ease of deployment and low power requirements mean it can be efficiently used in static and mobile deployments alike. For agencies focused on advancing response times and situational awareness, BAT is a game-changing tool in the world of modern defense.

Through innovations like the BAT, Gridbots is pushing forward the capabilities of AI and robotics in defense applications, making gunshot detection more accessible, reliable, and actionable.
